CSF Chevrolet C6 Corvette High-Performance All-Aluminum Radiator

7223

Stock: Backorder Available

RRP AU$1,569.00

AU$1,412.09 Inc GST

Save: AU$156.91 - 10% OFF

Description

Description

  • 2-Row, 52mm Ultra-High-Performance Core
  • Cooling Tubes with CSF’s Exclusive B-Tube Technology
  • 8mm Tall Ultra Efficient Fins with a Multi-Louvered Design for Maximum Surface Area Contact
  • Shorter core height provides clearance for supercharger installations
    • No need to modify the radiator core support or trim the radiator
    • Fits all OEM and Aftermarket Intake Systems
  • CNC Machined Mounting Brackets and OEM Style Inlet/Outlet
    • Mounting Pins have Cotter Pin Holes for securing A Corvette’s Top Shroud
  • Built In Engine Oil cooler & Automatic Transmission Cooler with Factory-style Quick Connect Fittings
  • 100% All Aluminum TIG-Welded Construction
  • Hand Brushed Satin Finish
  • True Plug-and-Play “Drop-in Fit” Installation Requires Absolutely No Modifications
  • Individually Leak and Pressure Tested
  • 2-Year Limited Warranty
Feature CSF OEM
# Core Rows 2 1
# Cooling Tubes 40 39
# Cooling Fin Rows 41 40
Fin Height/Width 8mm 9mm
Core Thickness 52mm 33.9mm
Core Material Aluminum Aluminum
Tank Material Aluminum Plastic
Construction 100% TIG Welded Crimp on Gasket




Fitment

Fitment

2005-2013 Chevrolet C6 Corvette (excluding 2011-2013 Z06, ZR1, 427 Model)
