About this product
Fits: 2016–2023 Toyota Tacoma 4WD
Durability, longevity, and versatility all come to mind when thinking of a Toyota Tacoma. Belltech mirrors these qualities in our 3rd generation Tacoma 4WD complete lift kit – a solution that elevates functionality and performance.
The front end utilises two heavy-duty powder-coated steel 4″ strut spacers and two 2″ preload spacers, delivering a total of 6″ of lift without straining other suspension elements. This increases clearance and creates room for larger tyres and wheels. Belltech lift spindles, made from ductile iron and powder-coated for longevity, reduce weight, increase strength, and maintain proper ball joint angles to retain factory geometry, turning radius, and track width.
High-clearance 1/4″-thick steel crossmembers lower the control arms to preserve geometry and integrate a differential mounting point. Differential drop brackets mimic OE alignment. The kit is compatible with the OE skid plate and adds a lower 1/4″-thick skid plate to protect the differential. A steering stop bracket prevents overextension, and sway bar relocation brackets maintain proper alignment.
At the rear, Trail Performance Twin Tube Shocks provide preset, low-friction damping tuned specifically for the Tacoma, with 55 mm bodies and 35 mm independent rebound and compression valves for controlled low and high-speed damping. Heavy-duty powder-coated 4″ lift blocks and extended U-bolts add height, while a carrier bearing spacer drops the driveshaft to retain factory pinion angles.
High-quality hardware and relocation brackets ensure brake lines are appropriately positioned. With factory alignment preserved, installation is straightforward. Tackle new roads and challenging terrain with confidence.
- Rear Trail Performance Twin Tube shocks
- 55 mm shock bodies
- 35 mm independent rebound and compression valves
- Rear lift blocks add 4″ of height
- 4″ strut spacers up front
- 2″ preload spacers for a total 6″ front lift
- Retains factory alignment and OE suspension geometry
- Differential drop-down bracket included
- High-clearance, rigid crossmembers
- 1/4″ skid plate protects the differential
- Retains factory track width and turning radius
- Easy installation with high-quality hardware
- Improved ride quality and added clearance
