CSF 2017-2020 Ford Raptor & 2015-2025 F-150 High-Performance Radiator

8095
CSF Radiators

Stock: Backorder Available

AU$1,679.00 Inc GST

Description

Description

  • 2-Row – 42mm Ultra-High-Performance Core
  • Cooling Tubes with CSF’s Exclusive B-Tube Technology
  • 6.5mm Tall Ultra Efficient Fins with a Multi-Louvered Design for Maximum Surface Area Contact
  • CNC Machined Mounting Pins and Brackets
  • OEM Style Inlet/Outlet
  • Core straps for strength and added rigidity
  • 100% All Aluminum TIG-Welded Construction
  • True Plug-and-Play “Drop-in Fit” Installation Requires Absolutely No Modifications
  • Individually Leak and Pressure Tested
  • 2-Year Limited Warranty
Feature CSF OEM
# Core Rows 2-Row 1-Row
Core Thickness 42mm 26mm
# Cooling Tubes 53 56
# Cooling Fin Rows 54 57
Fin Height/Width 6.5mm ~6.4mm
Core Material Aluminum Aluminum
Tank Material Aluminum Plastic
Construction 100% TIG Welded Crimp on Gasket

Fitment

Fitment

  • 2017-2020 F-150 Raptor 3.5L V6 EcoBoost
  • 2021-2025 F-150 5.0L V8
  • 2015-2020 F-150 5.0L V8
  • 2021-2025 F-150 3.5L V6 EcoBoost
  • 2015-2020 F-150 3.5L V6 EcoBoost
  • 2021-2025 F-150 2.7L V6 EcoBoost
  • 2015-2020 F-150 2.7L V6 EcoBoost
  • 2018-2020 F-150 3.0L V6 Turbo Diesel
  • 2021-2023 F-150 3.3L V6
  • 2018-2020 F-150 3.3L V6
  • 2015-2017 F-150 3.5L V6
  • 2018-2021 Ford Expedition 3.5L V6 EcoBoost
  • 2018-2021 Lincoln Navigator 3.5L V6 EcoBoost
